Forged flange Globe valves

Category

Forged steel globe valve is a commonly used shut-off valve, mainly used to connect or cut off the medium in the pipeline, and generally not used to regulate flow. The cut-off valve is suitable for a wide range of pressure and temperature. This valve is suitable for small diameter pipelines, with a sealing surface that is not easily worn or scratched, good sealing performance, small valve disc travel during opening and closing, short opening and closing time, and small valve height

myv-yina@myvalvemyv.com Enquiry

product description

qualifications

quality

qc inspection procedure

Specification(NPS)	F.P	3/8	1/2	3/4	1	1¹/4	1¹/2	2
Structure length(mm)	L	186	186	186	186	232	232	310
Handwheel diameter(mm)	w	200	200	200	200	280	280	300
Height(mm)	H	329	329	329	329	350	350	383
Flow port dimension(mm)	d	9	11	14	19	25	28	35
Weight(Kg)		10.8	11.6	12.3	12.3	28	26.4	43.8

What is a globe valve？
Forged steel Globe valves are suitable for small diameter pipelines with a working temperature of -29~425 ℃ (carbon steel) or -29~500 ℃ (stainless steel) in Class150~2500. They are used to cut off or connect the medium in the pipeline. Different materials are selected and can be used for various media such as water, steam, oil, nitric acid, acetic acid, oxidizing medium, urea, etc.
Product Description:

Main features:
Full bore or reduced bore
2. Self sealing valve cover
3. Rising pole with bracket
4. Automatic adjustment of packing pressure sleeve at both ends;
5. Body inverted seal
6. Integral valve body flange
7. Ring connected valve body and valve cover gasket
8. Bolted, threaded, welded, or self sealing valve covers with spiral wound gaskets

Product specifications:

Design standards: API 602, ANSI B16.34
Structure length: ANSI/ASME B16.10
Connection standard: ANSI/ASME B16.5
Test inspection: APl598
Main material: forged steel
Nominal diameter: 3/8 "-4"
Pressure range: 150LB-4500LB
Applicable temperature: -29-425 ℃
Applicable media: water, oil, natural gas, etc

Strive for excellence in every aspect
1. Quality: Carefully produce each product, ensuring quality
2. Price: Factory direct sales, no intermediate links, much cheaper than offline specialty stores
3. Workmanship: With superb technology, every detail is controlled in place and strives for excellence
4. Material: Choose high-quality materials, rich production experience, and better understand your needs
